DCS – LINUX

DCS – LINUX

Specifications

  • Dimensions: 122 mm (H) × 444 mm (W) × 356 mm (D) (allow extra for cables)

  • Weight: ~14 kg (≈30.9 lbs)

  • Analogue Outputs:

    • 1 stereo balanced pair on 2 × 3-pin XLR; output impedance 3 Ω.

    • 1 stereo unbalanced pair on 2 × RCA; output impedance 52 Ω.

    • Output voltage selectable: 0.2 V, 0.6 V, 2 V, or 6 V RMS for full-scale input.

  • Digital Inputs:

    • 2 × AES/EBU on 3-pin XLR (44.1-192 kS/s) — used as Dual AES pair supporting up to 384 kS/s.

    • 1 × S/PDIF BNC Coax (44.1-192 kS/s).

    • 1 × S/PDIF RCA (44.1-192 kS/s).

    • 1 × Toslink Optical (44.1-96 kS/s).

    • 1 × USB Type B (44.1-384 kS/s PCM & DSD; DSDx2 asynchronous).

    • 1 × USB Type A (for mass-storage devices, navigated via the Mosaic app).

  • Supported Formats / Sample Rates:

    • PCM: 44.1-384 kS/s up to 24-bit.

    • DSD: DSD64, DSD128 (Native + DoP depending on input)

    • File types: FLAC, WAV, AIFF, MQA.

  • Frequency Response (with Filter 1):

    • For Fs = 44.1 kS/s or 48 kS/s: ±0.1 dB from 10 Hz-20 kHz.

    • For Fs = 88.2 or 96 kS/s: ±0.1 dB 10 Hz-20 kHz; –3 dB at >38 kHz.

    • For Fs = 176.4 or 192 kS/s: −3 dB at >67 kHz.

    • For Fs = 352.8 or 384 kS/s: −3 dB at >100 kHz.

  • Residual Noise (6 V output setting):

    • For 16-bit data: Better than –96 dB0, 20 Hz-20 kHz (unweighted).

    • For 24-bit data: Better than –113 dB0, 20 Hz-20 kHz (unweighted).

  • L-R Crosstalk: Better than −115 dB0, 20 Hz-20 kHz.

  • Streaming & Networking:

    • Built-in network interface (Ethernet RJ-45) supporting UPnP, Internet Radio, Qobuz, Tidal, Spotify, Deezer, Roon Ready.

    • App control via Mosaic for settings, firmware updates.

  • Power Requirements: Auto-switching 90-127 V / 220-240 V, 50/60 Hz. Power consumption approx. 30 W.
